Saunum Air L 13 is a revolutionary new 13kW sauna heater with a sauna climate regulating system that is ideal for creating an extraordinary sauna session in a more intensively used sauna. The large stone volume of the Saunum Air L 13 and the patented air-blending system ensures exceptional steam that is soft and long, and evenly distributed throughout the sauna.
– Air Mixing Technology: Saunum’s patented air blending system mixes cold, oxygen-rich air from the floor with hot, oxygen-poor air off the ceiling to solve the discomfort so many associate with sauna. Whether you like it extremely hot or just warm, Saunum delivers both in a way that heat and oxygen is felt head to toe.
– European Design: Combines Scandinavian design and quality materials with an elegant black steel finish. Select the simple elegance of the Nordic black steel body.
– Massive Stone Capacity: Stones are the heart of a Nordic sauna. Ample stones result in softer, more even heat, and can produce more luxurious steam. The Air L boasts a massive 198-pound stone capacity (requires 6 boxes, sold separately).
– Himalayan Salt Reservoir: Saunum’s Himalayan salt tray is positioned within the air stream so that salt ions are propelled throughout the sauna to deliver health benefits more effectively.
– Dry Your Sauna: Go ahead, toss water onto the rocks! Saunum is engineered for water-tossing, and when you're done enjoying the steam, the patented fan system will conveniently help dry your sauna.
– UL Certification: Safety and reliability are priorities at Saunum, and each product is engineered to exceed strict UL standards.
– Available Aromatherapy: Add another sensory layer with Saunum's optional aromatherapy system, which infuses aroma into the steam to further transform your experience.
– Sauna Room Size Compatibility: Suitable for sauna rooms from 317 to 565 cubic feet.
Air L 13 Heat Equalizing System
Model: Air L 13
Certification / Global Safety Rating: UL (Underwriters Laboratories)
Heat/Steam Equalizer Module: 3-Speeds, Whisper-Quiet Operation
Air Intake & Output:
- Ceiling Hot Air Intake: 17.72" x 4" (450.09 x 101.6 mm)
- Cool Air Intake Type: Adjustable Valve, Side-Mounted, 12" (304.8 mm) Off Floor
- Cool Air Intake Size: 2" x 2.75" (50.8 x 69.85 mm)
- Blended Air Output: 4.31" x 14.13" (109.47 x 358.9 mm)
Himalayan Salt & Aroma Tray:
- Type: Removable, Slotted
- Size: 16.5" x 4.5" (419.1 x 111.76 mm)
Air L 13 Sauna Heater System
Model: Air L 13
Certification / Global Safety Rating: UL (Underwriters Laboratories)
Heater Body Style: Solid Steel – Nordic Black
Heating Elements: Incoloy (Stainless Steel)
Heating Element Protection: Air Tunnels, Slotted Stainless Steel, Three
Room Size Compatibility: 317 – 565 ft³ (10 – 14 m³)
Wattage Rating: 13,000 W
Operating Voltage: 240 VAC
Phase: Single (1)
Amperage: 54 A
Weight: 147 lbs (67 kg)
Shipping Weight with Stones: 345 lbs (157 kg)
Heater Dimensions:
- Depth: 18.1" (460 mm)
- Width: 19" (483 mm)
- Height (including telescopic air intake): 72.25" – 95" (1850 – 2400 mm)
Minimum Ceiling Height: 79" (2007 mm)
Stone Capacity & Size:
- Stone Capacity: 198 lbs (90 kg)
- Stone Size (sold separately): 2" – 4" (5 – 10 cm)
Electrical Requirements:
- Circuit Breaker Required: 70 Amp
- Wire Size to Power Unit: (2) #6 + N + G
Includes:
- Saunum Air L 13 Sauna Heater
- Hot Air Intake Cap
- Hot Air Intake
- Stone Basket
- Air Outake Grille
- Cool Air Intake Valve
- Protective Grill
- Himalayan Salt Spheres (7)
- Himalayan Salt Tray
- Temperature Sensor
- Installation and Operation Manual
- UL-listed
- 2-Year Warranty (Consumers Use)
